Resilient SSH Config for Google Cloud VMs: Connecting IDE Agents via IAP Tunnel

TL;DR

A resilient ~/.ssh/config block using gcloud compute start-iap-tunnel as a ProxyCommand is the cleanest way to connect local IDEs (Antigravity, VS Code, Cursor) to a Google Compute Engine (GCE) VM. Unlike gcloud compute config-ssh, this approach survives ephemeral IP changes when VMs stop and start, keeps your port forwards declarative, and explicitly pins --project and --zone so switching your active gcloud CLI defaults never breaks your connection.

The Problem with Wrapper Scripts and config-ssh

Many developers start connecting to a Google Cloud sandbox VM using a shell script around gcloud compute ssh:

#!/bin/bash
gcloud compute ssh --zone "europe-west3-b" "my-sandbox-vm" \
  --project "my-sandbox-project" \
  --ssh-flag="-L 8000:localhost:8000" \
  --ssh-flag="-L 8090:localhost:8090"

While convenient in a terminal, wrapper scripts create three friction points when working with AI-native IDEs like Antigravity, VS Code Remote-SSH, or Cursor:

1. IDEs Require Standard SSH Hosts: Remote IDE extensions read ~/.ssh/config host aliases directly—they cannot execute custom bash wrapper scripts.
2. gcloud compute config-ssh Hardcodes Ephemeral IPs: Running gcloud compute config-ssh populates ~/.ssh/config with static HostName IP addresses. Every time you stop and restart your VM, the external IP changes and breaks your config until you re-run the command.
3. Default Context Drift: If you switch your active gcloud config set project or compute/zone for another task, commands that rely on ambient CLI defaults suddenly fail to find your VM.

How the IAP ProxyCommand Pattern Works

flowchart LR
    subgraph Local ["Local Workstation"]
        IDE["IDE (Antigravity / VS Code)\nssh my-sandbox-vm"]
        SSH["~/.ssh/config\n(LocalForward + Keys)"]
        Proxy["ProxyCommand:\ngcloud compute start-iap-tunnel\n(--project & --zone pinned)"]
    end

    subgraph GCP ["Google Cloud"]
        IAP["Identity-Aware Proxy (IAP)"]
        VM["Compute Engine VM\n(my-sandbox-vm)"]
    end

    IDE --> SSH
    SSH --> Proxy
    Proxy ==>|Encrypted Stdin/Stdout Tunnel| IAP
    IAP ==>|Port 22 + Forwarded Ports| VM

Instead of connecting to an IP address directly, OpenSSH invokes gcloud compute start-iap-tunnel under the hood and pipes the SSH protocol over standard input/output (--listen-on-stdin).

Step-by-Step Configuration

1. Ensure Your GCE SSH Key Exists

If you have logged into any Compute Engine VM using gcloud compute ssh at least once, Google Cloud CLI has already generated your key pair at ~/.ssh/google_compute_engine.

If not, generate and propagate it once by running a dry run or initial login:

gcloud compute ssh my-sandbox-vm \
  --project="my-sandbox-project" \
  --zone="europe-west3-b" \
  --dry-run

2. Add the Resilient Host Entry to ~/.ssh/config

Open ~/.ssh/config and add a dedicated Host block with explicit --project and --zone flags in the ProxyCommand:

Host my-sandbox-vm
    IdentityFile ~/.ssh/google_compute_engine
    UserKnownHostsFile ~/.ssh/google_compute_known_hosts
    IdentitiesOnly yes
    CheckHostIP no
    HostKeyAlias compute.my-sandbox-vm
    StrictHostKeyChecking accept-new
    ProxyCommand gcloud compute start-iap-tunnel my-sandbox-vm %p --listen-on-stdin --project=my-sandbox-project --zone=europe-west3-b --verbosity=warning
    LocalForward 4000 localhost:4000
    LocalForward 8000 localhost:8000
    LocalForward 8090 localhost:8090

Why Each Directive Matters

Connecting from Antigravity or VS Code

Once saved in ~/.ssh/config:

1. Via IDE Remote Explorer: Open Antigravity (or VS Code), open the Remote-SSH connection menu, and select my-sandbox-vm.
2. Via Terminal: Simply run:

   ssh my-sandbox-vm


As long as the VM instance is running, your IDE and terminal will connect with all port forwards active—regardless of IP changes or which Google Cloud project your CLI is currently targeting.

[!TIP] Provisioning a New Sandbox VM? Check out the companion guide on Building an Agentic Sandbox: Provisioning a Google Cloud VM Workstation for setting up service accounts, IAM roles, and Vertex AI scopes.
